Automatic panel edge trimming saw
Finished size
|
1220*2440mm/815*1830mm
|
Workable thickness
|
5-50mm
|
Dia. of sawing blade
|
305mm
|
Working speed
|
30-50m/min
|
Size of sawing table
|
Horizontal 7m*2m*1.1m, Vertical Saw:5.7m*3.2m*1.2m
|
Speed of saw
|
90-120r/s
|
Total power
|
34.4 Kw
|
Total weight
|
5000kgs
|
No. of cylinder
|
4 pcs
|
Conveying way
|
Chain and guiding rail
|
Control system
|
Semi-automatic PLC control or Automatic PLC control
|
High precision guiding rail, exact cutting precision
Unique design, no burs and furs
Adjustable cutting size, suitable for 4*8 feet and 3*6 feet
PLC control, easy to operate
Automatic cutting and stacking can be designed, labor saving
|
